Specialized-exclusive X-Fusion shock offers adjustable rebound and lockout
control for fine-tuned performance.
The RockShox Tora fork delivers a full 120mm of travel and tunability,
with externally adjustable rebound, preload and lockout.
Specialized alloy adjustable rise stem is lightweight and 3D-forged with a
stiff four-bolt face plate for tuned fit and perfect steering precision.
Avid Juicy hydraulic brakes provide exceptional stopping power and
reliability, with alloy-backed pads and size-specific CleanSweep rotors.
Our M4 manipulated alloy frame is updated for `09 with a new rocker design and
120mm travel. Sealed cartridge bearing pivots provide reliable performance.
Durable, low-profile Shimano Shadow SLX rear derailleur.
FRAME FSR XC M4 Manipulated Alloy ubing w/ new rocker design, bolt on
cable guides, 120mm travel, sealed cartridge pivot bearings, disc only,
replaceable rear derailleur hangerREAR SHOCK X Fusion 02RLA, Custom tuned
for Specialized, rebound adj. w/lock-out, 7.5x1.75", 2 bearing upper shock
mountFORK Rock Shox Tora 302 SL, 120mm, alloy steer, external rebound and
preload adj. w/ LO, S/M" "Standard", L/XL "Stiff" Coil spring.HEADSET 1-
1/8" Threadless, loose ball bearings w/ seals, black steel cupsSTEM
Specialized adjustable rise, four bolt 31.8mm clamp, 3D forged, S:75mm,
M:90mm, L/XL:105mmHANDLEBARS Specialized XC low rise, butted alloy, 640mm
wide, 8 degree up, 8 degree backsweepGRIPS Specialized thin lock on
gripFRONT BRAKE Avid Juicy 3SL full hydraulic, alloy backed brake pads,
cleansweep S/M: 185mm, L/XL: 203mm rotorREAR BRAKE Avid Juicy 3SL full
hydraulic, alloy backed brake pads, cleansweep S/M: 160mm, L/XL: 185mm
rotorBRAKE LEVERS Avid Juicy 3 SL Hydraulic FRONT DERAILLEUR Shimano
Deore, 34.9mm clamp, top swing, bottom pullREAR DERAILLEUR Shimano RD-M672
SLX Shadow, 9 speed, long cageSHIFT LEVERS Shimano SL-M531 Deore,
triggerCASSETTE Shimano HG-50, 9-speed, 11-34t CHAIN KMC X9, 9-speed
w/ reusable Missing LinkCRANKSET Shimano FC-M442-8, Octalink Spline,
replaceable rings w/ alloy outer, S: 170mm, others: 175mmvCHAINRINGS Shimano
22S x 32S x 44ABOTTOM BRACKET Shimano BB-ES25, Octalink spline, 68mm x
118mm PEDALS Specialized, 1pc., alloy body and cage, 9/16" RIMS
Specialized RHD, disc, double wall w/ eyeletsFRONT HUB Specialized Hi Lo
disc, CNC flange, QR, 32hREAR HUB Specialized disc, sealed cartridge
bearing, high/low flange w/ OS contact side, 32hSPOKES 1.8mm (15g)
stainless, black, alloy nipplesFRONT TIRE Specialized The Captain Sport,
26x2.2", 60 TPI, wire beadREAR TIRE Specialized The Captain Sport,
26x2.0", 60 TPI, wire beadINNER TUBES Specialized 26x2.0",
schraderSADDLE Specialized MTB, 7mm steel rails, 143mmSEATPOST
Specialized 6061 alloy, black, 30.9x350/400mm, setback head, 2-bolt micro
adjustSEAT BINDER Alloy collar w/ QR, 34.9mm clamp IDNOTES Protective
clear coat, derailleur hanger, reflectors, owners manual
Specifications subject to change without notice.
Size S M L XL
|
