Technical Specifications
 |
 |
| FRAME |
Specialized A1 Premium Aluminum frame, double-butted and formed DT/TT, externally relieved HT and forged dropouts w/ replaceable hanger and disc mount |
 |
| REAR SHOCK |
|
 |
| FORK |
SR Suntour SF11-XCT-JR-24-MLO, 50mm, 1pc. alloy lower, 25.4mm Hi-Ten stanchions, coil/mcu w/ preload adj., mechanical LO |
 |
| HEADSET |
1-1/8" threadless, loose ball |
 |
| STEM |
Alloy A-head, 4 bolt, 20 degree rise, 25.4mm clamp |
 |
| HANDLEBARS |
Kid's Riserbar, Alloy, 600mm wide, 30mm rise |
 |
| GRIPS |
Kraton |
 |
| FRONT BRAKE |
"V" brake, alloy linear pull, 1pc. pad |
 |
| REAR BRAKE |
"V" brake, alloy linear pull, 1pc. pad |
 |
| BRAKE LEVERS |
Junior reduced reach "V", alloy, linear pull compatible |
 |
| FRONT DERAILLEUR |
8-Speed, 31.8mm clamp |
 |
| REAR DERAILLEUR |
SRAM X.3 RD, 7sp direct mount |
 |
| SHIFT LEVERS |
SRAM 3.0 Comp 7sp grip shift |
 |
| CASSETTE |
Shimano 7-Speed, 14/34t Mega Range |
 |
| CHAIN |
KMC Z7 w/ reusable Missing Link |
 |
| CRANKSET |
SR Suntour 7-Speed Junior, square, 160mm w/ replaceable outer ring |
 |
| CHAINRINGS |
Steel 42 x 32 x 22, replaceable outer w/ chainguard |
 |
| BOTTOM BRACKET |
Sealed cartridge, square taper, 118mm |
 |
| PEDALS |
Composite body w/ reflectors, 9/16" |
 |
| RIMS |
Alex-HRXC, 24" alloy double wall, pinned w/ CNC sidewalls, 32h |
 |
| FRONT HUB |
Forged alloy, double sealed, ground race, QR, 32h |
 |
| REAR HUB |
Forged alloy, freewheel type, double sealed, ground race, QR, 32h |
 |
| SPOKES |
1.8mm (15g) stainless |
 |
| FRONT TIRE |
Specialized Fast Track Sport, 24" x 1.80", 60TPI, wire bead |
 |
| REAR TIRE |
Specialized Fast Track Sport, 24" x 1.80", 60TPI, wire bead |
 |
| INNER TUBES |
Schraeder valve |
 |
| SADDLE |
Body Geometry Kid's Rival, 7mm rail, front and rear bumpers |
 |
| SEATPOST |
Alloy, 27.2mm, micro adjust |
 |
| SEAT BINDER |
Alloy QR, nylon washer |
 |
| NOTES |
Chain stay protector, reflectors, clear coat, owners manual |
 |
Specifications subject to change without notice.
|
