Technical Specifications
 |
 |
| FRAME |
Specialized A1 Premium Aluminum, 20" frame, front suspension geo w/ low standover TT design, formed DT/TT, forged
dropouts w/ replaceable hanger |
 |
| FORK |
SR Suntour SF11-XCT-JR-20, 40mm, 1pc. alloy lower, 25.4mm Hi-Ten stanchions, coil/mcu w/ preload adj. |
 |
| HEADSET |
1-1/8" threadless |
 |
| STEM |
Alloy A-head, 4 bolt, 20 degree rise, 25.4mm clamp |
 |
| HANDLEBARS |
Hi-Ten riser bar, 40mm rise, 10 degree back sweep, 6 degree up |
 |
| GRIPS |
Kraton, Revo type |
 |
| BRAKE |
"V" brake, alloy linear pull, 1pc. pad |
 |
| CHAIN |
KMC Z50, 1/2" x 3/32" |
 |
| CRANKSET |
Forged alloy arms, steel single ring w/ dual roller chainguide |
 |
| CHAINRINGS |
36t w/ chainguard |
 |
| BOTTOM BRACKET |
Water sealed, 68mm x 128mm |
 |
| PEDALS |
Composite platform w/ reflectors, loose ball, 9/16" |
 |
| RIMS |
Alex C-1000, alloy single wall, 32h |
 |
| FRONT HUB |
Forged alloy, 32h, nutted axle |
 |
| REAR HUB |
Forged alloy, freewheel type, 32h, nutted axle |
 |
| SPOKES |
2mm (14g) stainless |
 |
| FRONT TIRE |
Specialized Roller, 20 x 2.125", 30TPI, wire bead |
 |
| REAR TIRE |
Specialized Roller, 20 x 2.125", 30TPI, wire bead |
 |
| INNER TUBES |
Schraeder valve |
 |
| SADDLE |
Specialized Kids Body Geometry, 1pc., 7mm rail w/ clamp |
 |
| SEATPOST |
Alloy, 27.2mm, micro adjust |
 |
| SEAT BINDER |
Alloy QR, nylon washer |
 |
| NOTES |
Chain stay protector, reflectors, clear coat, owners manual |
 |
Specifications subject to change without notice.
|
