FRAME Crosstrail A1 Premium Aluminium, formed TT, ORE DT, forged dropouts
w/ replaceable hanger, integrated kickstand mount, chainstay disc mount
FORK SR SunTour SF10-NVX-700C, alloy lower, 75mm travel, 28mm Hi-Ten
stanchions, coil spring
HEADSET 1-1/8" threadless, sealed loose ball bearings
STEM Melt Forged alloy, 2-bolt, 25.4mm, 15 degree rise
HANDLEBARS Hi-Ten riser bar, 25.4mm, 32mm rise, 620mm wide, 8 degree back
sweep, 6 degree up
GRIPS Specialized Enduro, closed end, 130mm
FRONT BRAKE Alloy linear pull, 1pc. pad
REAR BRAKE Alloy linear pull, 1pc. pad
BRAKE LEVERS Shimano EF-50 (integrated w/ shifter)
FRONT DERAILLEUR Shimano FD-C051BM, 31.8mm clamp, top swing, dual pull
REAR DERAILLEUR Shimano Altus, 7-speed
SHIFT LEVERS Shimano, ST-EF-50, 7-Speed, EZ fire plus
CASSETTE Shimano MF-TZ31-7, 7-speed, 13-34t Mega Range
CHAIN KMC Z7 w/ reusable Missing Link
CRANKSET SR-Suntour 7-speed Crank Set, square, fully riveted plastic
spider, w/ chainguard
CHAINRINGS 48 x 38 x 28T w/ chainguard
BOTTOM BRACKET Cartridge bearing, square spindle with crank stop right
side and capless bolts
PEDALS Composite platform body, sealed loose ball bearings
RIMS Alex Z-1000, 26", single wall, 36h
FRONT HUB Forged alloy, double sealed, ground race, QR
REAR HUB Forged alloy, double sealed, ground race, freewheel type, QR
SPOKES 2mm (14g) stainless
FRONT TYRE Specialized Borough XC Sport 700x45c, 60TPI, wire bead
REAR TYRE Specialized Borough XC Sport 700x45c, 60TPI, wire bead
INNER TUBES Schrader valve
SADDLE Specialized XC, Body Geometry, 143mm width, front and rear bumpers
SEAT POST Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
SEAT POST CLAMP Forged alloy
NOTES Chain stay protector, derailleur hanger, clear coat, owners manual
