Technical Specifications
 |
 |
| FRAME |
Specialized E5 aluminum, fully
manipulated tubing, smooth weld compact race design, 1.5" integrated
headset |
 |
| FORK |
Specialized FACT carbon, carbon legs,
aluminum crown and steerer, 1.5" lower bearing |
 |
| HEADSET |
1-1/8" upper and 1-1/5" lower Cr-Mo
cartridge bearings integrated w/ headset, 20mm cone spacer with 20mm of
spacers |
 |
| STEM |
Specialized Elite-Set, 3D forged
alloy, 4-position adjustable, 4-bolt 31.8mm clamp |
 |
| HANDLEBARS |
Specialized Elite, 6061 aluminum, 130
drop, 90 reach, 31.8mm |
 |
| TAPE |
Specialized S-Wrap, w/ gel |
 |
| FRONT BRAKE |
Tektro cold-forged, dual pivot w/
cartridge pads |
 |
| REAR BRAKE |
Tektro cold-forged, dual pivot w/
cartridge pads |
 |
| BRAKE LEVERS |
Shimano Tiagra STI |
 |
| FRONT DERAILLEUR |
Shimano Tiagra |
 |
| REAR DERAILLEUR |
Shimano Tiagra |
 |
| SHIFT LEVERS |
Shimano Tiagra STI |
 |
| CASSETTE |
Shimano HG-50, 9-speed, 12-25t |
 |
| CHAIN |
KMC X9 |
 |
| CRANKSET |
Shimano Tiagra |
 |
| CHAINRINGS |
50 x 34T |
 |
| BOTTOM BRACKET |
With crankset |
 |
| PEDALS |
Black cage, body & toe clips w/
strap |
 |
| RIMS |
Mavic CXP22 |
 |
| FRONT HUB |
Forged alloy Hub, sealed bearings, 28
hole, for J bend round spokes |
 |
| REAR HUB |
Forged aluminum, 32h, double sealed
ball bearings, cassette, QR |
 |
| SPOKES |
Stainless 14g |
 |
| FRONT TIRE |
Specialized All Condition, 700x23c,
aramid bead, 60TPI, w/ Flak Jacket protection |
 |
| REAR TIRE |
Specialized All Condition, 700x23c,
aramid bead, 60TPI, w/ Flak Jacket protection |
 |
| INNER TUBES |
Standard presta valve |
 |
| SADDLE |
Body Geometry Riva Road, w/ steel
rails |
 |
| SEATPOST |
Specialized Elite, carbon wrapped
alloy, two-bolt clamp, 27.2mm |
 |
| SEAT BINDER |
Alloy, 31.8mm |
 |
| NOTES |
Chain stay protector, chain catcher,
derailleur hanger, clear coat, owners manual |
 |
Specifications subject to change without
notice.
|
