Technical Specifications
 |
 |
| FRAME |
M4 hydroformed tubing, women's TT, DT
& XC Trail geometry, curved TT S&M, sealed cartridge bearings, bolt on cable
guides, replaceable derailleur hanger, 100mm travel |
 |
| REAR SHOCK |
RockShox Ario, air spring, rebound
adj. and LO, 6.5x1.5" |
 |
| FORK |
RockShox Tora TK, coil spring, alloy
steerer, preload and rebound adj., lighter spring on S/M, 100mm travel |
 |
| HEADSET |
1 1/8" upper and lower campy style
cartridge bearings for integrated alloy HT |
 |
| STEM |
Specialized XC, 3D forged alloy, 4-
bolt, 31.8mm clamp, adjustable rise |
 |
| HANDLEBARS |
Specialized XC low-rise, 6061 butted
alloy, S/M: 640mm wide, L: 660mm wide, 8 degree backsweep, 6 degree up,
31.8mm |
 |
| GRIPS |
Specialized XC lock-on |
 |
| FRONT BRAKE |
Tektro Draco, hydralic disc, ceramic
pads, Light Wave rotor, 160mm |
 |
| REAR BRAKE |
Tektro Draco, hydralic disc, ceramic
pads, Light Wave rotor, 140mm |
 |
| BRAKE LEVERS |
Tektro Draco hydralic |
 |
| FRONT DERAILLEUR |
Shimano FD-M660 SLX, E-type for DMD,
top swing, bottom pull |
 |
| REAR DERAILLEUR |
Shimano RD-M430 Alivo, long cage |
 |
| SHIFT LEVERS |
Shimano SL-M430 Alivio, 9-speed,
trigger |
 |
| CASSETTE |
Shimano HG30, 9-speed, 11-34t |
 |
| CHAIN |
KMC X9, 9-speed, w/ reuseable Missing
Link |
 |
| CRANKSET |
Custom Shimano FC-M430, Octalink
Spline, replaceable rings w/ alloy outer, S/M: 170mm, others: 175mm |
 |
| CHAINRINGS |
44A x 32Sx 22S 4-bolt, 4-bolt,
104/64mm |
 |
| BOTTOM BRACKET |
Shimano BB-ES25, Octalink spline,
cartridge bearing |
 |
| PEDALS |
Alloy platform, 9/16" |
 |
| RIMS |
RHD, alloy disc, double wall, pin
joint, eyelets, 24mm, 32h |
 |
| FRONT HUB |
Specialized Hi Lo disc, QR, 32h |
 |
| REAR HUB |
Specialized Hi Lo Disc, double sealed
cartridge bearing, 32h |
 |
| SPOKES |
1.8mm (15g) stainless |
 |
| FRONT TIRE |
Specialized "The Captain" Sport, 60
TPI, wire bead, 26x2.0" |
 |
| REAR TIRE |
Specialized "The Captain" Sport, 60
TPI, wire bead, 26x2.0" |
 |
| INNER TUBES |
Schraeder valve 26x2.0 |
 |
| SADDLE |
Specialized Women's BG Windie XC,
143mm width |
 |
| SEATPOST |
6061 alloy, 2-bolt micro adjust,
setback head, 30.9mm, 350mm |
 |
| SEAT BINDER |
34.9mm clamp ID, 7050 hard annodized
alloy collar w/ QR, black |
 |
| NOTES |
Protective clear coat, derailleur
hanger, reflectors, owners manual |
 |
Specifications subject to change without
notice.
|
