Frameset
Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame Alpha Red Aluminum w/ABP, Full Floater, E2 head tube, magnesium EVO
Link, oversized bearings, 120mm travel
Front Suspension Fox RP24, custom for Trek, "trail tuned" w/4-position
platform to lockout, air adjust, rebound, alloy steerer, 130mm
Rear Suspension Fox Float RP23 XV Air Can, custom "trail tuned" w/Pro
Pedal,
rebound; 7.5x2.0"
Wheels Bontrager Rhythm Elite wheel system, 28mm, tubeless ready
Tires Bontrager Jones XR w/Kevlar bead, 26x2.2/2.25"; 127 tpi
Drivetrain
Shifters SRAM X-9, 9 speed w/MatchMaker
Front Derailleur Shimano Deore XT
Rear Derailleur SRAM X-0
Crank Shimano Deore XT 44/32/22
Cassette SRAM PG970 11-32, 9 speed
Pedals CrankBrothers Custom Candy C
Components
Saddle Bontrager Race Lite w/hollow stainless steel rails
Seat Post Bontrager Race Lite, 5mm offset
Handlebars Bontrager Race Lite, 40mm rise, 31.8mm
Stem Bontrager Race X Lite, 7 degree, 31.8mm
Headset VP-A58ACT-TK AHS semi-cartridge
Brakeset Avid Elixir R Custom SL, hydraulic disc; 185mm rotors (160mm rear
rotor on 15.5, 17.5, 18.5")
|
