Avid Ultimate hydraulic disc brakes with lightweight magnesium lever body
and
carbon blade, stainless hardware and alloy-backed organic pads provide
modulation and control at every speed.
Lightweight FACT 9m Az1 carbon frame with M5 Alloy chainstays/seatstays,
integrated Brain mount and full cartridge bearing pivots with 120mm travel.
The Specialized AFR rear shock is designed with a Trail Tune Inertia
valve,
Brain Fade and adjustable rebound for the ultimate in terrain-sensing
technology.
The Specialized Future Shock S120 fork delivers 120mm of air-sprung travel
and
terrain-sensing technology, including Trail Tune, Brain Fade and rebound
adjust. Designed with a lightweight carbon crown and steerer.
FRAME Stumpjumper FSR FACT 9M carbon main triangle, Az1 construction, M5
alloy
SS/CS with Brain mount, DMD Direct Mount F.Der, full cartridge bearing pivots,
120mm travelREAR SHOCK Specialized AFR Brain Shock w/ remote Trail Tune
inertia
valve, rebound adj. and Brain Fade, 7.25x1.75"FORK Specialized Future
Shock
S120, 120mm travel, single sided air spring and damper, Trail Tune, Brain
Fade, rebound adj., carbon 1-1/8" to 1.5" steererHEADSET 1-1/8"
Threadless,
Campy style upper and OS lower cartridge bearingSTEM Specialized
adjustable
rise, 31.8mm clamp, 3D forged w/ CNC finishHANDLEBARS Specialized XC low
rise
31.8mm bar, 2014 butted alloy, 6 degree up, 8 degree backsweep, 640mm
wideGRIPS Specialized thin lock on grip (S/M) Specialized Thick lock on
grip
(L/XL)FRONT BRAKE Custom Avid Ultimate SL, alloy backed organic pads,
alloy
caliper, magnesium lever body w/ carbon blade, SS hardware package, S/M:
185mm, L/XL: 203mm rotorREAR BRAKE Custom Avid Ultimate SL, alloy backed
organic pads, alloy caliper, magnesium lever body w/ carbon blade, SS hardware
package, S/M: 160mm, L/XL:185mm rotorBRAKE LEVERS Custom Avid Ultimate SL
HydraulicFRONT DERAILLEUR Shimano M770 XT, DMD, top swing, dual
pullREAR
DERAILLEUR SRAM X-0, 9-speed, mid cageSHIFT LEVERS SRAM X-0,
carbon/aluminum 9-
speed triggerCASSETTE Shimano M770 XT, 9-speed, 11-34tCHAIN SRAM PC-
971, 9-speed
w/Power LinkCRANKSET Shimano FC-M770 XT, 2pc., S: 170mm, others:
175mmCHAINRINGS 22S x 32A x 44A, 4-bolt, 104/64mmBOTTOM BRACKET
Shimano M-770
XTPEDALS NoneRIMS DT Swiss XR 4.2D, 24mm w/ eyelets, 28/32hFRONT
HUB Specialized
Hi Lo disc, CNC flange, sealed cartridge bearing, Oversized end caps, 9mm DT
RWS, alloy QR, 28hREAR HUB Custom DT Swiss 280S w/ Star Rachet, alloy
freehub
w/ DT RWS, 10mm alloy QR, 32hSPOKES DT Swiss Super Comp 2.0/1.7/1.8mm
butted
stainless, black, alloy nipplesFRONT TIRE S-Works The Captain Control,
26x2.2",
120 TPI, Aramid bead, dual compound, tubeless readyREAR TIRE S-Works The
Captain Control, 26x2.2", 120 TPI, Aramid bead, dual compound, tubeless
readyINNER TUBES Specialized Ultralight 26x2.0", prestaSADDLE
Specialized
Format, Ti rails, SL foam, S/M: 130mm L/XL:143mmSEATPOST Thomson Elite
Setback
w/ 12 degree clamp, S/M: 367mm L/XL: 410mmSEAT BINDER 7050 hard annodized
alloy
collar w/ QR, 36.9mm clamp ID, for carbon frame blackNOTES Protective
clear
coat, derailleur hanger, reflectors, owners manual
Specifications subject to change without notice.
Size S M L XL
|
