Frame Pitch frame, M4 tubing, double ORE downtube, DMD front derailleur
mount, sealed cartridge bearing pivots, replaceable hanger, bolt on cable
guides, 150mm travel
Rear Shock Fox RP2, 2 position shock with pro-pedal or full-open,
rebound adj., 7.875x2.25"
Fork Rockshox Pike 351 for Specialized, 140mm travel, Solo air, Motion
Control damper, disc only, alloy steerer, rebound adj., Maxle light included
Head Set 1-1/8" threadless, loose ball
Stem 3D forged alloy, 4-bolt, 31.8mm, 8 degree rise
Handlebars Alloy mid rise bar, 31.8mm, 680mm wide, 9 degree back sweep,
6 degree up
Tape / Grips Specialized waffle lock on grip (S/M) Specialized Thick lock
on grip (L/XL)
Front Brake Custom Avid Elixir 4, full hydraulic, alloy backed organic
pads, G2 Clean Sweep rotor, 203mm
Rear Brake Custom Avid Elixir 4, full hydraulic, alloy backed organic
pads, G2 Clean Sweep rotor, 185mm
Brake Levers Avid Elixir 4 Hydraulic
Front Derailleur Shimano M660 SLX, DMD, top swing, dual pull
Rear Derailleur SRAM X-9, 9-speed, mid cage
Shift Levers SRAM X5 trigger
Cassette Shimano HG50, 9-speed, 11-34t
Chain KMC X9 w/ reusable Missing Link
Crank Set Truvativ GXP2 2.2, 2-piece crank set, AA rings, outboard
bearing BB,
S: 170mm, M/L: 175mm
Chainrings 36 x 24T
Bottom Bracket Truvativ outboard bearing, included w/ crank
Pedals None
Rims Pitch Disc specific, 26mm, pin joint, eyelets, 32h
Front Hub Hi-Lo disc, 20mm thru-axle, 36h
Rear Hub Disc, double sealed cartridge bearing, high/low flange w/ OS
contact
side, 32h, QR
Spokes 1.8mm (15g) stainless
Front Tyre Specialized Eskar Control, 26x2.3", 60 TPI, tubeless ready,
aramid bead
Rear Tyre Specialized Eskar Control, 26x2.3", 60 TPI, tubeless ready,
aramid
bead
Inner Tubes Ultralight presta valve
Saddle Specialized Enduro BG, 7mm Cr-Mo rails
Seat Post 6061 alloy, 2-bolt micro adjust setback head, 30.9mm
Seat Post Clamp / Binder Alloy collar w/ QR, 34.9mm clamp ID
Notes Protective clear coat, derailleur hanger, reflectors, owners manual
|
