Technical Specifications
 |
 |
| FRAME |
M4 hydroformed tubing, women's TT, DT
& XC Trail geometry, curved TT S&M, sealed cartridge bearings, bolt on cable
guides, replaceable derailleur hanger, 100mm travel |
 |
| REAR SHOCK |
RockShox Ario, air spring, rebound
adj. and LO, 6.5x1.5" |
 |
| FORK |
RockShox Recon Gold TK, Turn Key
damper, Solo Air, alloy steerer, rebound adj. w/ LO, disc only, 100mm
travel |
 |
| HEADSET |
1 1/8" upper and lower campy style
cartridge bearings for integrated alloy HT |
 |
| STEM |
Specialized XC, 3D forged alloy, 4-
bolt, 31.8mm clamp, adjustable rise |
 |
| HANDLEBARS |
Specialized XC low-rise, 6061 butted
alloy, S/M: 640mm wide, L: 660mm wide, 8 degree backsweep, 6 degree up,
31.8mm |
 |
| GRIPS |
Specialized XC lock-on |
 |
| FRONT BRAKE |
Custom Avid Elixir 3 R SL, hydraulic
disc, tool-less reach adjust, alloy backed organic pads, G3 Clean Sweep, 160mm
|
 |
| REAR BRAKE |
Custom Avid Elixir 3 R SL, hydraulic
disc, tool-less reach adjust, alloy backed organic pads, G3 Clean Sweep, 140mm
|
 |
| BRAKE LEVERS |
Custom Avid Elixir 3 SL hydraulic,
tool-less reach adj. |
 |
| FRONT DERAILLEUR |
Shimano FD-M660 SLX, E-type for DMD,
top swing, bottom pull |
 |
| REAR DERAILLEUR |
Shimano RD-M772 Deore XT Shadow, long
cage |
 |
| SHIFT LEVERS |
Shimano SL-M430 Alivio, 9-speed,
trigger |
 |
| CASSETTE |
Shimano HG30, 9-speed, 11-34t |
 |
| CHAIN |
KMC X9, 9-speed, w/ reuseable Missing
Link |
 |
| CRANKSET |
Shimano FC-M521, Hollowtech, Octalink
spline, replacable rings w/ alloy outer, S/M: 170mm, L: 175mm |
 |
| CHAINRINGS |
44A x 32Sx 22S, 4-bolt, 104/64mm |
 |
| BOTTOM BRACKET |
Shimano BB-ES25, Octalink spline,
cartridge bearing |
 |
| PEDALS |
Resin Test Ride Pedals with toe clips,
CEN std. |
 |
| RIMS |
Custom DT Swiss 445D, alloy disc,
double wall, pin joint, eyelets, 24mm, 32h |
 |
| FRONT HUB |
Specialized Hi Lo disc, QR, 32h |
 |
| REAR HUB |
Specialized Hi Lo disc, double sealed
cartridge bearing, QR, 32h |
 |
| SPOKES |
1.8mm (15g) stainless |
 |
| FRONT TIRE |
Specialized "The Captain" Sport, 60
TPI, wire bead, 26x2.0" |
 |
| REAR TIRE |
Specialized "The Captain" Sport, 60
TPI, wire bead, 26x2.0" |
 |
| INNER TUBES |
Ultralight presta valve |
 |
| SADDLE |
Specialized Women's BG Windie XC,
143mm width |
 |
| SEATPOST |
6061 alloy, 2-bolt micro adjust,
setback head, 30.9mm, 350mm |
 |
| SEAT BINDER |
34.9mm clamp ID, 7050 hard annodized
alloy collar w/ QR, black |
 |
| NOTES |
Protective clear coat, derailleur
hanger, reflectors, owners manual |
 |
Specifications subject to change without
notice.
|
