Technical Specifications
 |
 |
| FRAME |
Myka M4 fully manipulated alloy frame,
fully butted, women's geometry, integrated HT, forged dropouts w/ replaceable
hanger, disc only |
 |
| FORK |
RockShox Tora SL Le Femme, magnesium
lower, 32mm Cr-Mo stanchions, 1 1/8" alloy steerer, coil spring w/ preload
adj., turn key damping w/ LO & external reb. adj. |
 |
| HEADSET |
Integrated 1-1/8" threadless, Campy
type full cartridge bearings |
 |
| STEM |
3D forged alloy, 4 bolt, 7 degree
rise, 31.8mm clamp |
 |
| HANDLEBARS |
Butted 31.8mm alloy riserbar, 25mm
rise, 8 degree back sweep, 6 degree up |
 |
| GRIPS |
Specialized Myka, dual density Kraton,
130mm |
 |
| FRONT BRAKE |
Shimano BR-M505 hydraulic disc brake,
dual piston, 160mm rotor |
 |
| REAR BRAKE |
Shimano BR-M505 hydraulic disc brake,
dual piston, 160mm rotor |
 |
| BRAKE LEVERS |
Shimano BR-M505 hydraulic |
 |
| FRONT DERAILLEUR |
Shimano FD-M4306 Alivo 9sp, 34.9mm
clamp, top swing, dual pull |
 |
| REAR DERAILLEUR |
Shimano RD-M592 Deore Shadow 9sp long
cage |
 |
| SHIFT LEVERS |
Shimano SL-M590 Deore 9sp trigger |
 |
| CASSETTE |
Shimano HG50, 9-speed, 11-34t |
 |
| CHAIN |
KMC X9 w/ reusable Missing Link |
 |
| CRANKSET |
Shimano FC-M430-8, Octalink spline |
 |
| CHAINRINGS |
44A x 32S x 22S replaceable |
 |
| BOTTOM BRACKET |
Shimano BB-ES25, Octalink spline,
cartridge bearing, 68mm x 118mm |
 |
| PEDALS |
Alloy 1pc. body and cage, reflector
kit, 9/16" |
 |
| RIMS |
Alex RHD 26", alloy double wall,
pinned w/eyelets |
 |
| FRONT HUB |
Forged alloy, hi/low flange, double
sealed, ground race, machined disc mount and flange, QR, 28h |
 |
| REAR HUB |
Forged alloy, mid flange, double
sealed, ground race, machined disc mount and flanges, cassette, QR, 32h |
 |
| SPOKES |
2mm (14g) stainless |
 |
| FRONT TIRE |
Specialized The Captain Control,
26x2.0", 60TPI, tubeless ready aramid bead |
 |
| REAR TIRE |
Specialized The Captain Control,
26x2.0", 60TPI, tubeless ready aramid bead |
 |
| INNER TUBES |
Presta valve |
 |
| SADDLE |
Body Geometry Women's Riva MTB, 155mm
width |
 |
| SEATPOST |
Alloy two bolt, 12.5mm offset, micro
adjust, 30.9mm |
 |
| SEAT BINDER |
Forged alloy QR, brass washer |
 |
| NOTES |
Chain stay protector, reflectors,
clear coat, owners manual |
 |
Specifications subject to change without
notice.
|
