Frameset
Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame Alpha Red Aluminum w/Hi/Lo chainstays, oversized bearings, 120mm
travel
Front Suspension RockShox Tora 302 Coil w/rebound, TurnKey lockout, alloy
steerer, 120mm
Rear Suspension Fox Float RP2 w/air pressure, Pro Pedal, rebound; 7.5x2.0"
Wheels Shimano M495 disc hubs; Bontrager Ranger rims w/welded seams and
eyelets
Tires Bontrager Jones XR, 26x2.2/2.25"; 30 tpi
Drivetrain
Shifters Shimano Deore, 9 speed
Front Derailleur Shimano Deore
Rear Derailleur Shimano Deore
Crank Shimano M442 Octalink 44/32/22
Cassette SRAM PG950 11-34, 9 speed
Pedals Alloy platform w/clips and straps
Components
Saddle Bontrager Race Basic
Seat Post Bontrager SSR, 20mm offset
Handlebars Bontrager Race, 40mm rise, 650mm width
Stem Bontrager SSR, 10 degree, 31.8mm
Headset VP-A76C AHS semi-cartridge
Brakeset Shimano M486 hydraulic disc; 180mm rotors (160mm rear rotor on
15.5,
17.5, 18.5")
|
