Frameset
Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Black Carbon w/ABP, Full Floater, E2 head tube, magnesium EVO
Link,
oversized bearings, 120mm travel
Front Suspension Fox F120 RL, custom for Trek, "trail tuned" w/air adjust,
lockout, rebound, E2 alloy steerer, 120mm
Rear Suspension Fox Float RP23 XV Air Can, custom "trail tuned" w/Pro Pedal,
rebound; 7.5x2.0"
Wheels Bontrager Rhythm Elite wheel system, 28mm, tubeless ready
Tires Bontrager Jones XR w/Kevlar bead, 26x2.2/2.25"; 127 tpi
Drivetrain
Shifters Shimano Deore XT
Front Derailleur Shimano Deore XT
Rear Derailleur Shimano Deore XT "Shadow"
Crank Shimano Deore XT 44/32/22
Cassette SRAM PG970 11-32, 9 speed
Pedals n/a
Components
Saddle Bontrager Race Lite w/hollow stainless steel rails
Seat Post Bontrager Race Lite, 5mm offset
Handlebars Bontrager Race X Lite Carbon, 40mm rise, 31.8mm
Stem Bontrager Race X Lite, 7 degree, 31.8mm
Headset Frustum Cane Creek SE Light Edition; 1 1/8" top, 1.5" bottom
Brakeset Shimano Deore XT Ti hydraulic disc, custom Ti for Trek; 180mm
rotors
(160mm rear rotor on 15.5, 17.5, 18.5")
|
