Frame FACT 9m carbon front triangle, IS construction, M5 aluminium rear
triangle. sealed cartridge bearing pivots, 100mm travel, replaceable
derailleur hanger
Rear Shock Specialized/Fox remote Mini-Brain, inertia valve, w/ Brain
fade adjust
Fork RockShox SID Race for Specialized, 100mm travel, air spring, rebound
and floodgate compression adj.w/ LO, alloy steerer
Head Set 1-1/8" Threadless, Campy style upper and lower cartridge
bearing
Stem 3D forged alloy, adjustable rise, 31.8mm clamp
Handlebars Specialized XC low rise bar, 7050 butted alloy, 31.8mm,
660mm wide, 8 degree back sweep, 6 degree up
Tape / Grips Specialized thin lock on grip (S/M) Specialized Thick lock
on grip (L/XL)
Front Brake Custom Avid Elixir R Carbon SL, alloy backed semi-met pads,
S/M: 160mm, L/XL: 185mm rotor
Rear Brake Custom Avid Elixir R Carbon SL, alloy backed semi-met pads,
S/M: 140mm, L/XL: 160mm rotor
Brake Levers Custom Avid Elixir R Carbon SL Hydraulic, carbon lever
blade, tool-less adj. reach
Front Derailleur Shimano M660 SLX, DMD, top swing, dual pull
Rear Derailleur SRAM X-0, 9-speed, mid cage
Shift Levers SRAM X-9 aluminium trigger
Cassette Shimano HG61, 9-speed, 11-34t
Chain SRAM PC-971, 9-speed w/Power Link
Crank Set Custom Shimano FC-M762 XT, 2pc., S: 170mm, others: 175mm
Chainrings 44A x 32A x 22S, 4-bolt, 104/64mm
Bottom Bracket Custom Shimano BB-91, OS, press-in bearing
Pedals None
Rims Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
Front Hub Specialized Hi Lo disc, CNC flange, sealed cartridge
bearing, 28mm oversized endcaps, 9mm DT RWS, alloy QR, 28h
Rear Hub Custom DT Swiss 330SL w/ alloy freehub, QR, 32h
Spokes DT Swiss Competition 1.8/1.6mm stainless
Front Tyre S-Works The Captain, 26x2.0", 120 TPI, tubeless ready Kevlar
bead, dual compound
Rear Tyre S-Works Fast Trak LK, 26x2.0", 120 TPI, tubeless ready
Kevlar bead, dual compound
Inner Tubes Ultralight presta valve
Saddle Specialized Phenom, hollow Cr-Mo rails, thin foam, S/M:
130mm, L/XL: 143mm
Seat Post 2014 butted alloy, single bolt setback, 30.9mm
Seat Post Clamp / Binder 7050 hard anodised alloy collar w/ QR,
36.9mm clamp ID, for carbon frame
Notes Protective clear coat, derailleur hanger, reflectors, owners manual
|
