Our M4 manipulated alloy frame is updated for `09 with a new rocker design
and
120mm travel. Sealed cartridge bearing pivots provide reliable performance.
Specialized-exclusive X-Fusion shock offers adjustable rebound and lockout
control for fine-tuned performance.
The RockShox Recon fork delivers a full 120mm of travel with lockout
control
and a Turn Key damper for adjustable rebound.
Specialized alloy adjustable rise stem is lightweight and 3D-forged with a
stiff four-bolt face plate for tuned fit and perfect steering precision.
Avid Juicy hydraulic brakes provide exceptional stopping power and
reliability, with tool-less reach adjust, alloy-backed pads and size-specific
CleanSweep rotors.
The long-cage Shimano Deore Shadow rear derailleur shifts smoothly and
reliably, with a new low-profile design that improves durability.
FRAME FSR XC M4 Manipulated Alloy tubing w/ new rocker design, bolt on
cable
guides, 120mm travel, sealed cartridge pivot bearings, disc only, replaceable
rear derailleur hangerREAR SHOCK X Fusion 02RC, Custom tuned for
Specialized,
rebound adj., compression adjust w/lock-out, 7.5x1.75", 2 bearing upper shock
mountFORK RockShox Recon 335 SL, 120mm travel, 32mm alloy stanchions,
alloy
steerer, disc only, Turn Key damper, rebound adj. w/ LO, air springHEADSET
1-
1/8" Threadless, loose ball bearings w/ seals, black steel cupsSTEM
Specialized
adjustable rise, four bolt 31.8mm clamp, 3D forged, S:75mm, M:90mm,
L/XL:105mmHANDLEBARS Specialized XC low rise, butted alloy, 640mm wide, 8
degree up, 8 degree backsweepGRIPS Specialized thin lock on gripFRONT
BRAKE Avid
Juicy 4 RSL Hydraulic Disc Brake, alloy backed organic brake pads, tool-less
reach adj., cleansweep rotor S/M:185mm rotor, L/XL:203mm rotorREAR BRAKE
Avid
Juicy 4 RSL Hydraulic Disc Brake, alloy backed organic brake pads, tool-less
reach adj., cleansweep rotor S/M:160mm rotor, L/XL:185mm rotorBRAKE LEVERS
Avid
Juicy 4RSL Hydraulic FRONT DERAILLEUR Shimano Deore, 34.9mm clamp, top
swing,
bottom pullREAR DERAILLEUR Shimano RD-M772 Deore XT Shadow, long
cageSHIFT
LEVERS Shimano SL-M531 Deore, triggerCASSETTE Shimano HG-50, 9-speed, 11-
34t
CHAINKMC X9, 9-speed w/ reusable Missing LinkCRANKSET Shimano FC-M521,
Hollowtech, Octalink spline, replacable rings w/ alloy outer, S: 170mm,
others: 175mmCHAINRINGS Shimano 22S x 32S x 44ABOTTOM BRACKET Shimano
BB-ES25,
Octalink spline, 68mm x 118mm PEDALS Shimano 505 SPD, reflectors and
cleatsRIMS DT Swiss 445D, disc, 24mm, double wall, pin joint, eyelets, 32h
FRONT HUBSpecialized Hi Lo disc, CNC flange, QR, 32hREAR HUB Specialized
disc,
sealed cartridge bearing, high/low flange w/ OS contact side, 32hSPOKES
1.8mm
(15g) stainless, black, alloy nipplesFRONT TIRE Specialized The Captain
Sport,
26x2.2", 60 TPI, wire beadREAR TIRE Specialized The Captain Sport,
26x2.0", 60
TPI, wire beadINNER TUBES Specialized Ultralight 26x2.0",
prestaSADDLE Specialized MTB, 7mm steel rails, 143mmSEATPOST
Specialized 6061
alloy, black, 30.9x350/400mm, setback head, 2-bolt micro adjustSEAT
BINDER Alloy collar with QR, 34.9mm clamp IDNOTES Protective clear coat,
derailleur hanger, reflectors, owners manual
Specifications subject to change without notice.
Size S M L XL
|
