Frame FSRxc M4 tubing, rocker design, bolt on cable guides, 120mm travel,
sealed cartridge pivot bearings, disc only, replaceable rear derailleur hanger
Rear Shock X Fusion 02RLA, Custom tuned for Specialized, rebound adj.
w/lock-out, 7.5x1.75", 2 bearing upper shock mount
Fork Rock Shox Tora SLite, 120mm travel, alloy steer, magnesium lower,
rebound and preload adj. w/ LO
Head Set 1-1/8" threadless, loose ball
Stem 3D forged alloy, 4-bolt, 31.8mm, adjustable rise
Handlebars XC low rise, 6061 butted alloy, 660mm wide, 8 degree back
sweep, 6 degree up
Tape / Grips Specialized waffle lock on grip (S/M) Specialized thick lock
on grip (L/XL)
Front Brake Avid Juicy 3 SL hydraulic disc, alloy backed brake pads,
calliper/adapter w/ Clean Sweep Rotor, S/M: 185mm, L/XL: 203mm
Rear Brake Avid Juicy 3 SL full hydraulic, alloy backed brake pads, w/
Clean Sweep Rotor, S/M: 160mm, L/XL: 185mm rotor
Brake Levers Avid Juicy 3 SL Hydraulic
Front Derailleur Shimano FD-M590 Deore, 34.9mm clamp, top swing,
bottom pull
Rear Derailleur Shimano RD-M662 SLX Shadow, long cage
Shift Levers Shimano SL-M531 Deore, trigger
Cassette Shimano HG50, 9-speed, 11-34t
Chain KMC X9 w/ reusable Missing Link
Crank Set Shimano FC-M442, Octalink Spline, replaceable rings w/ alloy
outer,
S: 170mm, others: 175mm
Chainrings 44A x 32S x 22S
Bottom Bracket Shimano BB-ES25, Octalink spline, cartridge bearing, 68mm
x
118mm
Pedals Alloy body and cage, 9/16"
Rims Alex RHD, disc, double wall w/ eyelets, 32h
Front Hub Forged alloy, hi/low flange, double sealed, ground race,
machined
disc mount, 32h, QR
Rear Hub Disc, double sealed cartridge bearing, high/low flange w/ OS
contact
side, 32h, QR
Spokes 1.8mm (15g) stainless
Front Tyre Specialized The Captain Sport, 26.2.2", 60 TPI, wire bead
Rear Tyre Specialized The Captain Sport, 26x2.0", 60 TPI, wire bead
Inner Tubes Schrader valve
Saddle Specialized Rival, Body Geometry, 143mm width, front and
rear bumpers
Seat Post 6061 alloy, 2-bolt micro adjust setback head, 30.9mm
Seat Post Clamp / Binder Alloy collar w/ QR, 34.9mm clamp ID
Notes Protective clear coat, derailleur hanger, reflectors, owners manual
|
