THE FEATURES
Technical Specifications
 | |
| |
| FRAME | A1 Premium Aluminum, double-butted TT and Arched DT, machined head tube, arched down tube, forged dropouts with replaceable hanger |
| |
| FORK | RST Capa T5, 51mm travel, alloy steer, Cr-Mo 25.4mm stanchions, Coil/MCU with preload adjust, cold forged alloy crown, 1-piece alloy lowers with mini boots |
| |
| HEADSET | 1 1/8 threadless, sealed loose ball |
| |
| STEM | A-Head, 1-1/8 alloy, 15 degree rise, 11-60mm/14-75mm length |
| |
| HANDLEBARS | Alloy, flat, 6 degree sweep, 540mm width |
| |
| TAPE / GRIPS | Kraton 'Revo' style |
| |
| FRONT BRAKE | Tektro, alloy linear pull, stainless steel pipe, 60mm all weather pads |
| |
| REAR BRAKE | Tektro, alloy linear pull, stainless steel pipe, 60mm all weather pads |
| |
| BRAKE LEVERS | Tektro junior V, alloy, linear pull compatible |
| |
| FRONT DERAILLEUR | Shimano Acera, 31.8mm clamp, bottom pull |
| |
| REAR DERAILLEUR | Shimano Altus |
| |
| SHIFT LEVERS | Shimano RS-41 'Revo' twist shifters, 3/7speed |
| |
| FREEWHEEL | Shimano HG37, 7 speed, 14x28t |
| |
| CHAIN | Shimano IG |
| |
| CRANKSET | Truvativ ISO Flow, alloy 160mm with replaceable chainrings and capless bolts |
| |
| CHAINRINGS | Truvativ 42t 7075alloy, heat-treated Cr-Mo 32t and 22t |
| |
| BOTTOM BRACKET | Truvativ, square taper, 68x113mm, Cr-Mo spindle, sealed cartridge bearing, drive static side crank stops |
| |
| PEDALS | Steel cage, resin body(toe clip compatible) with reflectors |
| |
| RIMS | Alex 24'x 1.50, alloy, double wall, pinned with CNC side walls |
| |
| FRONT HUB | Alloy, 32 hole, double sealed with alloy QR |
| |
| REAR HUB | Alloy, 32 hole, double sealed with alloy QR, freewheel type |
| |
| SPOKES | 2.0mm (14g) stainless steel, brass nipples, L239/R239mm front, L237/R236mm rear |
| |
| FRONT TIRE | Specialized Roll X 24x1.8 blackwall |
| |
| REAR TIRE | Specialized Roll X 24x1.8 blackwall |
| |
| TUBES | Specialized schraeder valve |
| |
| SADDLE | Specialized Mini Mountain |
| |
| SEAT POST | Alloy, micro adjust, 27.2x300mm |
| |
| SEAT BINDER | Specialized forged alloy, 31.8mm I.D., withalloy QR |
| |
| NOTES | Chain stay protector, reflectors, clear coat, owners manual |
| |
