THE FEATURES
Technical Specifications
 | |
| |
| FRAME | A1 Premium Aluminum, freeride-style with formed tubes, kid’s 24” hardtail with forged dropouts and replaceable hanger |
| |
| FORK | RST Capa C5, 51mm travel, Hi-Ten steer and 25.4mm stanchions, coil, cold forged alloy crown, 1-piece alloy lowers |
| |
| HEADSET | 1 1/8” Threadless, sealed loose ball |
| |
| STEM | A-Head alloy, 15 degree rise, 60mm length |
| |
| HANDLEBARS | Steel, 30mm rise,10 degree sweep, 540mm width |
| |
| TAPE / GRIPS | Specialized Kraton 'Revo' style |
| |
| FRONT BRAKE | Tektro, alloy linear pull, stainless steel pipe, 60mm all weather pads |
| |
| REAR BRAKE | Tektro, alloy linear pull, stainless steel pipe, 60mm all weather pads |
| |
| BRAKE LEVERS | Tektro junior “V”, alloy, linear pull compatible |
| |
| FRONT DERAILLEUR | Shimano FD-Co5o, 31.8mm clamp, bottom pull |
| |
| REAR DERAILLEUR | Shimano Tourney |
| |
| SHIFT LEVERS | Shimano Revo, twist 3 front, 7 rear |
| |
| FREEWHEEL | Shimano HG37, 7 speed, 14x28t |
| |
| CHAIN | Shimano IG |
| |
| CRANKSET | Specialized forged alloy 160mm |
| |
| CHAINRINGS | 42Sx34Sx24S |
| |
| BOTTOM BRACKET | Square taper, 68mm shell, 128mm spindle, water sealed loose ball |
| |
| PEDALS | Junior resin platform with reflectors |
| |
| RIMS | Alex, alloy 24x1.5', single wall withground sidewalls |
| |
| FRONT HUB | Alloy, 36 hole, sealed loose ball, nutted axle |
| |
| REAR HUB | Alloy, 36 hole, sealed loose ball, nutted axle |
| |
| SPOKES | 2.0mm (14g), stainless steel, brass nipples, L236/R236mm front, L235/R234mm rear |
| |
| FRONT TIRE | Specialized Roller 24x2.125” blackwall |
| |
| REAR TIRE | Specialized Roller 24x2.125” blackwall |
| |
| TUBES | Specialized schraeder valve |
| |
| SADDLE | Specialized Expert Jumping |
| |
| SEAT POST | Alloy, micro adjust, 27.2x300mm |
| |
| SEAT BINDER | Integrated, with chromed allen head binder |
| |
| NOTES | Chain stay protector, reflectors, clear coat, owners manual |
| |
